PP Threaded Adjustable Ball Nozzle

q
PP Threaded Adjustable Ball Nozzle

Item No.: KB-C

Material: PP

Delivery Time:  In Stock

Features of  Threaded Adjustable Ball Nozzle,adjustable spray nozzles,adjustable spray nozzles

1)Improve spray system performance; Threaed Adjustable Ball Nozzle
2)No tools required for installation;reduce installation and maintenance time
3)Chemically-resistant material

4)Designed for easy installation and minimal maintenance downtime

the KB-C Clip-Eyelet nozzle assembly simply snaps onto an existing header. Ball-type Clip-Eyelet nozzle tips are quickly installed and aligned, then secured with a retaining cap — all by hand. Whether you’re removing the entire assembly or just the spray tip,you'll save time with the Threaded Adjustable Ball Nozzleassembly.


Clamp's size of  Threaded Adjustable Ball Nozzle,adjustable spray nozzles,K-Ball Clip-on Nozzles,Flat Fan Nozzles

Adjustable Threaded Ball are available in single- or double-clamp styles to accommodate pressure requirements up to 150 psi(10 bar).
Designed to clamp on 3/4",1",1-1/4",1-1/2" or 2" pipe, Adjustable Ball Bases fit 14mm or 16mm drilled inlet openings with retrofit seals available for additional inlet sizes.



Male thread size of Threaded Adjustable Ball Nozzle usually have  1/8" ,1/4", 3/8", 1/2" male connection



Specification Data of  Threaed Adjustable Ball Nozzle,Threaded Ball nozzle,adjustable spray nozzles,Clip Eyelet Nozzle ,K-Ball Clip-on Nozzles,PP Flat Fan Nozzles:



Application of Adjustable Threaded Ball,K-Ball Clip-on Nozzles,Flat Fan Nozzles

Clip-Eyelet nozzles are used for the pretreatment of aluminum channels prior to painting, cleaning, coating, and rinsing.



Detailed Pics of Adjustable Ball Type Nozzle,adjustable spray nozzles,Adjustable Threaded Ball

Adjustable Spray Nozzles

Adjustable Spray Nozzles
